Servo-Hydraulic Press
High-Precision & Energy-Efficient Solution for Advanced Forming
Price : ＄12,000 - ＄56,000
Shuntec servo-hydraulic press machine is the servo-driven hydraulic press machine integrated with the precision pressure and position transducer for closed-loop control. Our servo-hydraulic press machines are widely used in precision applications such as automobile parts forming, jigsaw puzzle die-cutting, precision straightening, deep drawing, trimming, compression molding, and so on.
| Industry | Typical Processes | User Benefits |
|---|---|---|
| Automotive | – Chassis component forming – Deep drawing of metal parts – Precision bending and punching |
– Precise force and position control – Energy-efficient operation with reduced noise – Enhanced process monitoring for quality assurance |
| Aerospace | – Forming of complex aerospace parts – Composite material shaping – Structural component assembly |
– High accuracy for intricate parts – Controlled pressure for delicate materials – Improved safety features with programmable settings |
| Metalworking | – Heavy-duty stamping – Coining and embossing – Large-part straightening |
– High tonnage capacity for demanding tasks – Smooth, controlled motion for precision work – Reduced maintenance compared to traditional hydraulic presses |
| Energy Sector | – Wind turbine component forming – Solar panel frame assembly – Power transmission equipment manufacturing |
– Consistent force application for structural integrity – Efficient energy use for high-output production – Advanced data logging for process optimization |
| General Manufacturing | – Die cutting – Mold pressing – Assembly of metal and plastic components |
– Flexible control settings for diverse tasks – High repeatability for improved product consistency – User-friendly interface for simplified operation |
| Parameter | Details |
|---|---|
| Warranty Commitment | 3-year full machine warranty + lifetime technical support |
| Global After-Sales | Overseas localized service teams (Europe/USA/Southeast Asia), 24/7 multilingual support (EN/DE/JP/CN) |
| Delivery Lead Time | 30-55 working days (standard models) / 60-90 working days (customized models) |
| Logistics Support | Full coverage of EXW/FOB/CIF/DDP terms, hazardous material packaging provided (IP67 protection) |
Contact a Trusted Servo-Hydraulic Press Manufacturer Today
Send Inquiry- Machine Video
- Machine Highlight
- Machine Specifications
- Machine Options
Machine Video
Machine Highlight
Compared to the conventional hydraulic press, the advances of the servo-hydraulic presses are obvious:
- First of all, much faster approaching, pressing, and return speed
- Speed adjustable during the whole stroke
- Pressure repeat accuracy ±1%
- Furthermore, 30%~60% lower energy consumption
- Much lower noise level
- All parameters programmable on the central color touchscreen
- High degree of reliability and minimum need for maintenance during the entire lifetime
Application of Shuntec servo-hydraulic press:
Precision force control and real-time production monitoring make the servo-hydraulic press the ideal machine equipment for most of the precision applications such as automobile parts forming and assembling, motor bearing assembling and press-fitting, the electric connector assembly and pressing, as well as the precision straightening, trimming, compression molding and so on. Owing to its energy-saving servo control, the heated platen servo-hydraulic press is now becoming more and more popular for hot compression molding applications with long pressure holding time.
Shuntec offers several standard 4-post servo-hydraulic press machines, with load pressure holding time. These standardized servo press systems can be modified with specific tonnage, stroke, shut height, and so on to meet your special need. Please note that we can design the servo-hydraulic presses with many other frame structures such as 2-post, C frame, H frame, and so on.
Machine Specifications
Product Datas
| Applicable Industries: | Precision forming, straightening,
Trimming, die-cutting, compression molding, deep drawing, etc |
Certification: | CE/UL/ISO |
| Power
Supply: |
380V/220V/415V/480V
optional |
Warranty: | 18 months |
| Customizable: | Highly customized to your requirements | Aftersales Service: | Field installation, commissioning
and training, online support, free spare parts, video technical support |
| Production Lead-time: | About 30~55 workdays | Payment Term: | T/T |
| Packing: | Plywood package suitable
for sea transport |
Delivery Term: | EXW, FOB,CFR,CIF,DDU |
Technical Parameters
| Description | Shuntec-P11 50T | Shuntec-P11 100T | Shuntec-P11 150T | Shuntec-P11 250T | Shuntec-P11 500T |
| Nominal Force | 500 KN | 1000 KN | 1500 KN | 2500 KN | 500 KN |
| Structure | Four-column | Four-column | Four-column | Four-column | Four-column |
| Cylinder Stroke | 150 mm | 2000 mm | 250 mm | 500 mm | 6000 mm |
| Max. Daylight | 400 mm | 500 mm | 5500 mm | 800 mm | 900 mm |
| Shut Height | 250 mm | 30 mm | 300 mm | 300 mm | 300 mm |
| Effective Table Area | 450*450 mm | 500*500 mm | 550*550 mm | 700*700 mm | 900*900 mm |
| Closing Speed | 130 mm/s | 110 mm/s | 155 mm/s | 170 mm/s | 140 mm/s |
| Slow Pressing Speed | 13.5 mm/s | 8.5 mm/s | 9 mm/s | 11 mm/s | 5.5 mm/s |
| Return Speed | 125mm/s | 110 mm/s | 145 mm/s | 195 mm/s | 140 mm/s |
| Motor | 4 Pole, 5.5KW | 4 Pole, 11KW | 4 Pole, 15KW | 4 Pole, 30KW | 4 Pole, 30KW |
| Power Supply | 3Phase, 220/380/415/480VAC, 50/60HZ | 3Phase, 220/380/415/480VAC, 50/60HZ | 3Phase, 220/380/415/480VAC, 50/60HZ | 3Phase, 220/380/415/480VAC, 50/60HZ | 3Phase, 220/380/415/480VAC, 50/60HZ |
| System Pressure | 20 Mpa | 20 Mpa | 20 Mpa | 25 Mpa | 25 Mpa |
| Machine Approx. Weight | 4.5 Ton | 5 Ton | 7 Ton | 11 Ton | 15 Ton |
| Machine Approx. Size | 1500*1350*2250 mm | 1650*1350*2300 mm | 1850*1450*2500 mm | 1950*1600*2650 mm | 2000*1800*2850 mm |
Machine Options
• 2-post, 4-post, c frame, h frame structures optional
• Interlocked, hinged guards on 3 sides
• Hydraulic center ejection
• Air blast valve with timer and air nozzles
• Removable base
• Portable operator console
• Safety ratchet bar
• Pneumatic safety rachet
• Automatic tie bar lubrication
• Top-mounted hydraulics
• Hanging Swivel Operation System
• Tonnage Monitor
• Automatic tie bar lubrication system
• T-slotted moving and bed platens
• Operator and supervisor access levels
• User customizable PLC access
• Job / die memory
